Ceiling dehumidifiers can usually be divided into three stages during installation

Time:2021/7/28 11:51:31

Dehumidifier is a kind of equipment widely used in our family life and industrial production. It can help us solve our moisture problem well. Among the many dehumidifiers, the ceiling dehumidifier is a more commonly used type. The ceiling dehumidifier can be divided into three stages during installation. Next, let the editor of the ceiling dehumidifier explain it.

One， Install dehumidifier

1. Installation of boom

Before installation, the installation location must be determined. After precise positioning with chalk and measuring tools at the specific installation location, drill holes at the specified location with a drill and install expansion screws.

2. Install dehumidifier

Before installing the ceiling dehumidifier, install four sets of M8 nuts 1, a spring washer and a flat washer on the four spacing screws in turn, and then move the ceiling dehumidifier horizontally upwards, insert the spacing screws into the lugs of the ceiling dehumidifier, and then Turn them individually. Insert nut 2 to install the desiccant on the expansion screw. Please note that the ceiling dehumidifier must not be turned over in any way, otherwise the ceiling dehumidifier will be damaged.

3. Horizontal installation

After the dehumidifier is installed, adjust the level detection fixing nut 2 to make the fuselage reach the installation level (to ensure that the dehumidifier can drain normally and avoid the hidden danger of water leakage). Then install nut 1 to lock the ceiling dehumidifier and complete the installation of the ceiling dehumidifier.

Second, the installation of the air duct

1. Installation of the intake pipe

The air inlet is as close to the casing as possible, and the height difference between the air inlet and the dehumidifier is as small as possible. The shorter the air inlet pipe, the better the dehumidification effect. The upper limit of the air inlet pipe must not exceed 1.5m, and it must be closely connected with the air inlet of the dehumidifier (no obstacles in front of the air inlet).

2. Install the air outlet

The distance between the air outlet and the fuselage should be as far as possible, but the upper limit of the air outlet should not exceed 5 meters, and the height difference of the air outlet of the dryer should be as small as possible, and the length of the air outlet should not exceed 5 meters. The air outlet of the dehumidifier must be tightly connected (no obstacles in front of the air outlet).

Three, install the drain pipe

The dehumidifier should be 5-10 cm higher than the drain pipe. The length of the drain pipe depends on the actual situation, but make sure that the drain pipe is not blocked. Ceiling dehumidifiers can be ceiling-mounted or suspended. After installation, it should be easy to maintain and ventilate.

The above three points are all about the ceiling dehumidifier can be divided into three stages during installation, thank you for your understanding and support!
